    Automation Solder Crimp Type AISG Connector Circular 8 Pin M12 Male Female M5

    Ask Lasest Price
    Brand Name : Ritian communication
    Model Number : M5 conn-001
    Certification : UL CE ROHS
    Price : Negotiable
    Supply Ability : 10000 Unit/Units per Month
    Delivery Time : 5-7 days
    • Product Details
    • Company Profile

    Automation Solder Crimp Type AISG Connector Circular 8 Pin M12 Male Female M5

    automation solder crimp type Circular 8 pin M12 Male Female M5 AISG china factory connector


    M5 circular plug forming cable is mainly used to connect the host with various sensors such as: temperature sensor, thermal sensor, acoustic sensor, photosensitive sensor, photoelectric sensor, etc. M5 connector cables are mainly used in robots, servo motors, controllers, encoders, human-machine interface industrial robots.


    Applications:

    The waterproof level of M5 can reach IP67, which can meet the needs of waterproof, dustproof, oil-proof and so on. This excellent waterproof connector is widely used in various products that require special protection, such as: LED street lights, water level recorders, remote water meters, water quality monitoring, navigation, lighthouses, cruise ships, industrial equipment, sprinklers, etc.


    Supply straight / angled male and female type connectors for free assembly with screw type wire connection.

    The field installable connectors permit high flexibility for wiring in the field. For quick assembly of often differing cable lengths, RITIAN supplies straight male and female type connectors for free assembly with screw type wire connection.

    · Screwing termination contacts.
    · Protection degree IP67.
    · 3-Pole,4-Pole are available.
    · Temperature range:-40℃~+125℃.
    · Operating voltage 250V-AD, current4A.


    Characteristics of M5 Series


    General Infomation
    Standard
    IEC 61076-2-105
    Insulation Resistance
    ≥100MΩ
    Ambient Temperature
    -25℃~+90℃/-20/- 40℃~+80℃
    Contact Resistance
    ≤5mΩ
    Connector Insert
    TPU/PA
    Shielding
    Unavailable
    Connector Contacts
    Brass with Gold Plated
    Seal/O-ring
    Epoxy resin/FKM
    Coupling Nut/Screw
    Brass with Nickel Plated
    Mating Endurance
    >500 cycles
    IP Rating
    IP67/68/IP69K in locked condition
    Certificate
    ULS/CE/ROHS/IP67/REACH/IP68
