    M16 3 Pin Metal Assembly IP67 Soldering Aviation Plug Connector Threaded Coupling

    Ask Lasest Price
    Brand Name : RITIAN
    Model Number : M16 Aviation plug connector
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    M16 3 Pin Metal Assembly IP67 Soldering Aviation Plug Connector Threaded Coupling

    M16 3pin Metal Assembly IP67 soldering Threaded coupling Male Female Aviation Plug AISG Connector


    Product Fetures

    1.Extremely strong resistant to acid,alkali,chemical cleaning agent /reagent properties;

    2.Resistant to welding spark,continually twist ;

    3.Resistant to oil,coolant ,lubricant and emulsion;

    4.Pin configurations:2,3,4,5,7,8,12,14,19,24 properties ;

    5.Shield and un-shield Version Available with metal or plastic housing;

    6.Meet IP67/IP68 waterproof requirements;

    7.Temperature Range:-25℃ ~ +85℃;



    M16 Connector
    Number of Positions2 / 3 / 4 / 5 / 6 / 7 / 8 / 12 / 14 / 24 Pin
    GenderMale / Female
    OrientationStraight / Right Angle
    Mounting TypePCB Mount / Panel Mount / Cable
    Shell MaterialMetal / Plastic
    Termination StyleScrew-joint / Solder Type
    ShieldShield / Unshielded

    Specifications:


    Temperature Range

    Solder,screw:-40℃/ +80℃

    Screw damp,biatec:-25℃/+80℃

    Moulded -25℃/+85℃

    Mechnical operation>100 mating cycles

    Rated voltage

    Impulse voltage

    60V(30V)UL

    2500V

    Pollution degree3
    Rated current4A
    Contact resistance≤8mΩ
    Insulation resistance≥500MΩ
    Protection degreeIP67
    StandardIEC61076-2-101
    Material:
    Contact platingAu(Gold)
    Material of housingPBT/PA/CuZn(brass)
    Cable materialPVC/PUR (cable length customized)
    Wire gauge

    Solder 0.25mm(AWG24)

    Screw 0.14mm-0.5mm(AWG26-20)

    Biatec 0.14mm-0.38mm(AWG26-22)

    LED/ShieldingWith or without
