    M12 right angle Panel mount Male Female automative 5 pin solder waterproof antenna AISG connector

    Ask Lasest Price
    Brand Name : Ritian
    Model Number : M12 M16 connector
    Certification : CE
    Price : Negotiated
    Payment Terms : L/C, T/T
    Supply Ability : 1000pcs per month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    M12 right angle Panel mount Male Female automative 5 pin solder waterproof antenna AISG connector

    M12 right angle Panel mount Male Female automative 5 pin solder waterproof antenna AISG connector


    Product Fetures

    1.Extremely strong resistant to acid,alkali,chemical cleaning agent /reagent properties;

    2.Resistant to welding spark,continually twist ;

    3.Resistant to oil,coolant ,lubricant and emulsion;

    4.Pin configurations:2,3,4,5,7,8,12,14,19,24 properties ;

    5.Shield and un-shield Version Available with metal or plastic housing;

    6.Meet IP67/IP68 waterproof requirements;

    7.Temperature Range:-25℃ ~ +85℃;


    M12 PCB connectors are front and rear bulkhead mounted M12 connectors designed for easy handling on the PCB and
    compatibility with wave soldering processes. M12 PCB connectors include an incorporated wire clip with an integrated PCB retention
    feature to secure it in the PCB during the reflow process, individual wires come stripped and pre-tinned ready for soldering.
    General features:
    Standard
    IEC 61076-2-101
    Termination
    Solder PCB
    Connector locking system
    Screw
    Degree of protection
    IP67, IP68, IP69K
    Ambient temperature(operation)
    -25°C~+85°C
    Mechanical operation
    >100 mating cycles
    Customs tariff number
    8538900000
    Environmental compliance
    RoHs, Reach
    Electrical parameters:
    Rated voltage
    30V~250V
    Rated impulse voltage
    500V
    Rated current(40°C)
    1.5A~4A
    Contact resistance
    ≤5mΩ
    Insulation resistance
    ≥100MΩ
    Materials:
    Connector body
    TPU
    Male pin
    Brass with gold plated
    Female pin
    Phosphorus copper with gold plated
    Shell
    Brass with nickel plated
    O-ring material
    Fluorine ring
    Black glue
    Epoxy resin

    M12 right angle Panel mount Male Female automative 5 pin solder waterproof antenna AISG connectorM12 right angle Panel mount Male Female automative 5 pin solder waterproof antenna AISG connectorM12 right angle Panel mount Male Female automative 5 pin solder waterproof antenna AISG connectorM12 right angle Panel mount Male Female automative 5 pin solder waterproof antenna AISG connector
